UT377A handheld pocket-sized moisture meter with built-in accurate detecting moisture technology. Designed with 2 high precision pins that can pinpoint pockets of moisture hidden within wood, firewood, paper, furniture, etc
Professional device for wood work. 4 Modes. Classifies wood into 4 categories based on material density. Measuring various types of wood with a refresh rate of 2 times/s. Temperature compensation algorithm is applied to ensure measurement accuracy
Stainless steel pins detect up to 2.6-inch (65mm) below surface. Survive quality abuse test for over 1000 times of constant uses. Wide scope of applications: wood, raw material, paper, furniture, firewood, logs, cardboard, floor and so on
Easy to use. Plugs in and gently swing to remove. Max/Min, data hold and LCD backlight for easy reading. 1-meter drop test durability for long term uses
Color: RED
Weight(KG): 0.200
Wood Moisture Measurement Range 2 to 4 PER CENT
Measurement Resolution 0.10 PER CENT
Measurement Accuracy 2 PER CENT
Wood Categories. 4
Ambient Temperature Correction
Refresh Rate 2 times
Auto range
Auto power off
Low battery indicator
Data Hold
MAX/MIN
Backlight
Working Temperature 0 DEG C to 40 DEG C
1m Drop Test
Power 1.5V battery X 3
HOW IT WORKS
Short press power button to turn on device.
Press wood symbol button to select wood type. (default mode is type 3).
Take off the protection cover and probe cap. To avoid missing parts insert the cap into the cover.
Insert the probe vertically into wood for measurement.
Readings on LCD screen is the absolute value of moisture content.
Press MODE to measure Max or Min value.
Press HOLD/BL button to select backlight or data hold.
To remove the device, in case of breaking the probe pin, please gently swing the device and loose it along the wood grain direction.
