Infrared Image

IR Resolution

96 × 96 (9,216 pixels)

SuperIR

240 × 240 (57,600 pixels)

Distance to Spot Ratio (D:S)

112:1

Image Frequency

25 Hz

NETD

< 50 mK (@ 25°C, F# = 1.0)

Detector Pitch

12 μm

Focal Length

1.35 mm

Spectral Range

7.5 to 14 μm

F-number

F1.0

Field of View (FOV)

50° × 50°

Spatial Resolution (IFOV)

8.89 mrad

Min. Focus Distance

0.1 m (0.33 ft)

Focus Mode

Focus Free

Image Display

Display

240 × 320 Resolution, 2.4”LCD Screen

Image Modes

Thermal/Visual/Fusion

Color Palettes

White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion

Color Alarm

Above alarm

Visual Camera

640 × 480

Measurement and Analysis

Object Temperature Range

-20°C to 550°C (-4°F to 1022°F)

Accuracy

Max (±2°C/3.6°F, ±2%) at ambient temperature 25°C (77°F) and object temperature above 0°C (32°F)

Measurement Tools

Center Spot, Hot Spot, Cold Spot

Level and Span Mode

Auto/Manual

Data Storage and Communication

Storage Media

Built-in 4 GB flash memory

Image Storage Capacity

Approx. 30,000 Images

General

USB Interface

USB Type-C

Laser

Yes, Class II

Battery Type

Rechargeable Li-ion battery

Battery Charging Time

Approx. 3 hours fully charged(Adapter Output: 5 V 2 A)

Battery Operating Time

Approx. 8 hours

Protection Level

IP54

Drop Test Height

2 m (6.56 ft)

Working Temperature Range

-10°C to 50°C (14°F to 122°F)

Storage Temperature Range

-40°C to 70°C (-40°F to 158°F)

Relative Humidity

< 95% non-condensing

Weight

Approx. 290 g (0.64 lb)

Dimension

196 × 117 × 59 mm (7.7” × 4.6” × 2.3”)

Tripod Mounting

UNC ¼”-20
