| Operating Principles | Senses the steady state electrostatic ?eld produced by AC Voltage through insulation without requiring contact to the bare conductor. A red gLow at the tip and a beeping Noise (if Not switched OFF) indicates the presence of Voltage. |
| Voltage sensing ranges | NoMinAlly, 90 V AC to 1000 V AC |
| Detector tip style | Flat-tip |
| Light source | One Hgh intensity red LED |
| Agency Approvals | c CSA us, CE, C-Tick |
| Safety Rating | 1000 V, CAT IV |
| Safety Compliance | Meets IEC 61010-1:2001, UL 61010-1 (2nd ed.), CAN/CSA-C22.2 No. 61010-1-04, and ISA-82.02.01 Pollution Degree 2 |
| EMC Compliance | Meets IEC 61326-1:2006 |
| IP Rating | IP 40 |
| Operating Temperature | -10°C to 50°C (-14°F to 122°F) |
| Operating Humidity Ranges | 0% to 95% (0°C to 30°C) |
| 0% to 75% (30°C to 40°C) | |
| 0% to 45% (40 to 55°C) | |
| Operating Altitude | 3000 m |
| Cleaning | Clean with damp cloth |
| Batteries | 2 AAA alkaline batteries included |
TDS : FLUKE 1AC-II AC Detector VOLTALERT Voltage Tester Pen 90V-1000V SDS : FLUKE 1AC-II AC Detector VOLTALERT Voltage Tester Pen 90V-1000V
